Enhancement of Discharge Capacity of Mg/MnO2 Primary Cell with Nano-MnO2-Graphene as Cathode

Selvam Mohanraj

Abstract


In the present study, pristine a-MnO2 and graphene mixed with nanoparticles a-MnO2-based cathode were prepared and their electrochemical performances were studied in a magnesium/ manganese dioxide-graphene (Mg/a-MnO2-graphene) primary battery cell. A modified Mg/MnO2-graphene primary cell was constructed using the prepared α-MnO2 nanoparticles [Sample A (α-MnO2) and Sample B (α-MnO2-graphene)] and electrochemically synthesized graphene in a Swagelok type cell. The discharge measurements of the modified Mg/MnO2 cell were analyzed using galvanostatic constant current (1, 5 and 10 mA) discharge with the cutoff voltage of 0.2V. The discharge capacity of α-MnO2 based cathode was 20, 46 and 73 mAhg-1 respectively at 1, 5, 10 mA constant current, respectively. Similarly the discharge capacity of α-MnO2-graphene based cathode was 68, 308 and 271 mAhg-1, respectively. Moreover, the discharge capacity of cathode based on α-MnO2-graphene increased three times compared to α-MnO2 based electrode. The present work unveils that graphene-a-MnO2 based cathode is suitable for primary magnesium battery application.


Keywords


Nanoparticles, Graphene, Cathode Material, Discharge Capacity, Modified Mg/MnO2 Primary Cell.

Full Text:

PDF

References


Soundararajan D, Kim Y, Kim JH, Kim KH, Ko JM. Hydrothermal Synthesis and Electrochemical Characteristics of Crystalline α-MnO2 Nanotubes. Science of Advanced Materials, 2012; 4, 805.

Kim SY, Jeong S. H, Lee E. Y, Park Y. H, Bae H. C, Jang Y. S, Maeng E. H, Kim M. K, Son S. W, Skin absorption potential of ZnO nanoparticles. Toxicology and Environmental Health Sciences, 2011; 3, 258.

Zhao X, Sanchez B. M, Dobson P. J, Grant P. S, The role of nanomaterials in redox-based supercapacitors for next generation energy storage devices. Nanoscale, 2011; 3, 839-855.

Wang, Dunqiang, et al. "Synthesis and electrochemical properties of submicron sized sheet-like LiV 3 O 8 crystallites for lithium secondary batteries." Materials Letters 71 (2012): 48-50.

Hiralal P, Imaizumi S, Unalan H. E, Matsumoto H, Minagawa M, Rouvala M, Nanomaterials-Enhanced All-Solid Flexible Zinc−Carbon Batteries. ACS Nano, 2010; 4, 2730-34.

Linden D, Reddy T. B, (eds.). Handbook of Batteries, McGraw- Hill, New York, 2002.

Girishkumar G, Munichandraiah N. Ageing of magnesium/manganese dioxide primary cells. Journal of Solid State Electrochemistry, 2001; 5, 8.

Ratnakumar B. V. Passive films on magnesium anodes in primary batteries. Journal of Applied Electrochemistry, 1988; 18(2), 268-279.

Ratna Kumar B. V, Sathyanarayana S. The delayed action of magnesium anodes in primary batteries Part I. Experimental studies. Journal of Power Sources, 1983; 10(3), 219–241.

Sathyanarayana S, and Ratna Kumar B. V. The delayed action of magnesium anodes in primary batteries: Part II. Theoretical studies. Journal of Power Sources, 1983; 10(3), 243–261.

Peng B, Liang J, Tao Z, Chen J. Magnesium nanostructures for energy storage and conversion. Journal of Materials Chemistry, 2009; 19, 2877.

Li C, Cheng F, Ji W, Tao Z, Chen J. Magnesium Microspheres and Nanospheres: Morphology- Controlled Synthesis and Application in Mg/MnO2 Batteries. Nano Research, 2009; 2, 713-721.

Devaraj S, Gabriel G. S, Gajjela S. R, Balaya P. Mesoporous MnO2 and Its Capacitive Behavior. Electrochemical and Solid-State Letters, 2012; 15, 57-59.

Yu P, Zhang X, Chen Y, Ma Y. Solution-combustion synthesis of ε-MnO2 for supercapacitors. Materials Letters, 2010; 64, 61-64.

Zolfaghari A, Ataherian F, Ghaemi M, Gholami A. Capacitive behavior of nanostructured MnO2 prepared by sonochemistry method. Electrochimica Acta, 2007; 52, 2806 – 2814.

Ai Z, Zhang L, Kong F, Liu H, Xing W, Qiu J. Microwave-assisted green synthesis of MnO2 nanoplates with environmental catalytic activity. Materials Chemistry and Physics, 2008; 111, 162.

Aravindan V, Reddy M. V, Madhavi S, Subba Rao G. V, Chowdari B. V. R. Electrochemical performance of α-MnO2 nanorods/activated carbon hybrid supercapacitor. Nanoscience and Nanotechnology Letters, 2012; 4, 724-728.

Bao S. J, He B. L, Liang Y. Y, Zhou W. J, Li H. L. Synthesis and electrochemical characterization of amorphous MnO2 for electrochemical capacitor. Materials Science and Engineering: A, 2005; 397, 305.

Zhang R, Yu X, Nam K. W, Ling C, Arthur T. S, Song W, Knapp A. M, Ehrlich S. N, Yang X. Q, Matsui M. α-MnO2 as a cathode material for rechargeable Mg batteries. Electrochemistry Communications, 2012; 23, 110.

N. Tang, X. Tian, C. Yang, Z. Pi, Q. Han. Facile synthesis of α-MnO2 nanorods for high-performance alkaline batteries. Journal of Physics and Chemistry of Solids, 2010; 71, 258 -262.

C. Yuan, B. Gao, L. Su, X. Zhang. Interface synthesis of mesoporous MnO2 and its electrochemical capacitive behaviors. Journal of colloid and interface science, 2008; Sci. 322, 545.

P. Saha, MK. Datta, OI. Velikokhatnyi, A. Manivannan, D. Alman, PN Kumta. Rechargeable magnesium battery: Current status and key challenges for the future. Progress in Materials Science, 2014; 66, 1-86.

N.Munichandraiah. Electrochemical impedance studies of a decade-aged magnesium/manganese dioxide primary cell. Journal of Applied Electrochemistry, 1999; 29, 4, 463-471.

S. U. Kim and C. W. Monroe. Increasing the rate capability of batteries with electrolyte flow. Journal of Applied Energy, 2013; 103, 207.

SRC. Vivekchand, CS. Rout, KS. Subramanyam, A. Govindaraj, CNR. Rao. Graphene- based electrochemical super capacitors. Journal of Chemical Science, 2009; 120:9–13.

H. Wu, J. Liu, IA. Aksay, Y. Lin. Graphene based electro chemical sensors and biosensors. Journal of Electro Analytical chemistry, 2010; 22(10):1027–36.

DB. Shinde, J. Debgupta, A. Kushwaha, M. Aslam, VK. Pillai. Electrochemical unzipping of multi-walled carbon nanotubes for facile synthesis of high-quality graphene nanoribbons. Journal of American Chemical Society, 2011; 133:4168.

EJ Yoo, J. Kim, E. Hosono, HS. Zhou, T. Kudo, I. Honma. Large reversible Li storage of graphene nanosheet families for use in rechargeable lithium ion batteries. Nano Letters, 2008; 8:2277–82.

C. Wang, D. Li, CO. Too, GG. Wallace. Electrochemical properties of graphene paper electrodes used in lithium batteries. Journal of Chemical Materials, 2009; 21(13):2604–06.

Zhang et al. α-MnO2 as a cathode material for rechargeable Mg batteries. Journal of Electrochemistry Communications, 2012; 23, 110–113.

G. Wang, B. Wang, J. Park, J. Wang, YB. Sun, J. Yao. High efficient and large-scale synthesis of graphene by electrolytic exfoliation. Carbon, 2009; 473:242–46.

M. Selvam, K. Sakthipandi, R. Suryaprabha, K. Saminathan, V. Rajendran. Synthesis and characterisation of electrochemically reduced graphene. Bulletin of Material Science, 2013; 36(7):1315–1321.

Z. Luo, Y. Lu, LA. Somers, AT. Johnson. High yield preparation of macroscopic graphene oxide membranes. Journal of American Chemistry, 2009; Soc 131(3):898–9.

M. O’Brien, B. Nichols. CVD synthesis and characterization of graphene thin films. Army research laboratory, 2010; ARL-TR- 5047.

A. Reina, X.T. Jia, LY. Ho. Large area, few-layer graphene films on arbitrary substrates by chemical vapor deposition. Nano Letters, 2009; 9(1):30–35.

A. Reina, XT. Jia, J. Ho, D. Nezich, H. Son, V. Bulovic, MS. Dresselhaus, J. Kong. Synthesis of N-doped graphene by chemical vapor deposition and its electrical properties. Nano Letters, 2009; 9(5):1752–1758.

Gopu Kumar, A. Sivashanmugam, N. Muniyandi. Para-Nitrotoluene as a depolarizer for magnesium batteries, Journal of Power Sources, 1992; 39: 1121–129.

M. Choucair, P. Thordarson, JA. Stride. Gram-scale production of graphene based on solvothermal synthesis and sonication. Nature Nanotechnology, 2009; 4:30–33.

DK. Singh, PK. Iyery, PK. Giriz. Improved chemical synthesis of graphene using a safer solvothermal route. International Journal of Nanoscience. 2011; 10(1): 1–4.

GI. Titelman, V. Gelman, S. Bron, RL. Khalfin, Y. Cohen, H. Bianco-Peled. Synthesis of water soluble graphene. Carbon, 2005; 43:641–649.

N. Liu, F. Luo, H. Wu, Y. Liu, C. Zhang, J. Chen. One-step ionic liquid- assisted electrochemical synthesis of ionic-liquid-functionalized graphene sheets directly from graphite. Advance Functional Material, 2008; 18: 1518–25.

A. Kaniyoor, T. Baby, S. Ramaprabhu. Graphene synthesis via hydrogen induced low temperature exfoliation of graphite oxide. Journal of material chemistry, 2010; 20: 8467–69.




DOI: http://dx.doi.org/10.26472/ijrae.v2i5.59
